ALZ-G200 Endoscopy Accessories
Single-Use Electronic Upper Gastrointestinal Imaging Catheter
A single-use electronic upper gastrointestinal imaging catheter for use with the company's medical endoscope image processor, with a 1300 mm working length and 3.2 mm or larger instrument channel.
- Model
- ALZ-G200
- Product family
- Endoscopy Accessories
01 · Overview
Designed for a clearer reprocessing workflow.
The ALZ-G200 Single-Use Electronic Upper Gastrointestinal Imaging Catheter is intended for use with the medical endoscope image processor manufactured by the company. With images displayed on a video monitor, it is used for observation, diagnosis, image capture and treatment of the upper gastrointestinal tract.
For the duodenal portion, the stated range is limited to the duodenal bulb and descending portion.
02 · Key features
Built around the workflow.
Key information from the current approved product profile.
Key information
Working dimensions
Specified with a 1300 mm working length, an insertion-section outer diameter of 11 mm or less and an instrument channel inner diameter of 3.2 mm or greater.
Viewing range
A 3-100 mm depth of field and a 140-degree field of view with a plus or minus 10 percent tolerance are specified.
Four-way angulation
Specified angulation is 210 degrees up, 90 degrees down and 110 degrees to both the left and right.
03 · Product information
Key specifications
- Model
- ALZ-G200
- Weight
- Approximately 0.57 kg
- Working length
- 1300 mm ± 5%
- Insertion-section outer diameter
- ≤ 11 mm
- Instrument channel inner diameter
- ≥ 3.2 mm
- Angulation
- Up 210°; down 90°; left 110°; right 110°
- Depth of field
- 3-100 mm
- Field of view
- 140° ± 10%
